UV Absorption Water Quality Monitor
AG-C08 UV absorption water quality monitor with RS485 Modbus RTU communication, IP68 protection and reagent-free fast measurement.
UV Absorption Water Quality Monitor for environmental monitoring projects
AG-C08 UV absorption water quality online monitor for COD and turbidity measurement in surface water, rivers, lakes, reservoirs, municipal wastewater, wastewater treatment and seawater monitoring.
AG-C08 is listed as a UV absorption online water quality monitor. It is relevant when a project needs fast sensor-based COD and turbidity trend measurement without wet-chemical reagents.
AG-C08 uses a UV absorption method with RS485 communication and Modbus RTU protocol. It can measure COD and turbidity at the same time, uses a corrosion-resistant stainless-steel body, supports self-cleaning, turbidity compensation and dual-beam measurement, and is suitable for surface water, river sections, lakes, reservoirs, municipal wastewater, wastewater treatment and seawater monitoring.
Technical data for model selection
Review the main measuring range, output interface, operating conditions and configuration notes before quotation.
Huisheng confirms the final model, range and site configuration according to sample condition and monitoring requirement.
| Item | Specification / selection note |
|---|---|
| Model | AG-C08 UV absorption online water quality monitor |
| Measured parameter | Ultraviolet absorption; can measure COD and turbidity at the same time according to the product range |
| Working principle | Dual-wavelength UV method |
| Measuring range | (0-200 / 1000) mg/L and (0-500) NTU |
| Measurement accuracy | <10% |
| Resolution | 0.1 mg/L |
| Communication interface | RS485, standard Modbus protocol |
| Electrode size | D32 mm, L175 mm, 3 m cable; cable can be configured |
| Operating condition | 0-60 degrees C, 0-3 bar |
| Power | 12V / 24V DC, 0.4W |
Configured around the actual monitoring point
The working method is confirmed according to selected model, monitored medium and project requirement.
Wastewater, surface water, process water or water network points
Temperature, moisture, dust, solids, corrosive components or compound type may affect configuration.
Analyzer, detector, sampler, cabinet, pretreatment and data output can be combined as one product package.
Specifications are prepared according to the selected model and actual project requirement.
Details Huisheng reviews before confirming a model
Huisheng reviews the product model together with the measured medium, target range, sampling condition, installation position and required specifications. This keeps the product discussion tied to the real monitoring point.
Expected concentration or detection level helps determine the model and measurement method.
Temperature, moisture, suspended solids, dust, corrosion or target compound behavior may change the configuration.
The working method is confirmed according to selected model, monitored medium and project requirement.
Indoor cabinet, outdoor station, shelter or process-side installation depending on site
Communication output, alarm logic and model-specific specifications depend on the selected model.
Monitoring indicators covered by this product series
The final parameter package depends on the selected model, measuring range, sample condition and data output requirement. For many projects, one instrument is part of a complete monitoring point rather than a stand-alone purchase.
AG-C08
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
UV absorption
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
COD + turbidity
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
IP68
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
RS485 Modbus RTU
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
Reagent-free
This item is confirmed by the selected model, measuring range, sample condition and site requirement.
How the product fits into a complete monitoring chain
Most projects connect the product with sample access, conditioning, measurement, data acquisition and reporting. The exact arrangement depends on the site and selected model.
UV optical measurement body
This part is configured according to the selected model and actual site conditions.
Self-cleaning structure
This part is configured according to the selected model and actual site conditions.
Turbidity compensation
This part is configured according to the selected model and actual site conditions.
RS485 Modbus RTU output
Data acquisition, alarm output and communication must match the project platform or reporting requirement.
Field mounting interface
This part is configured according to the selected model and actual site conditions.
Where this equipment is usually discussed
Water monitoring applications are selected by monitoring point first: discharge outlet, treatment process, river station, water network or industrial process water. The instrument scope then follows the parameter group, sample condition and cabinet arrangement.
Suitable for distributed water points where physical, nutrient or chemical indicators need continuous observation.
Configured according to the monitoring point, sample condition, installation environment and expected data use.
Used where discharge quality, treatment stability or final outlet trends need to be followed with clearer online data.
Used where discharge quality, treatment stability or final outlet trends need to be followed with clearer online data.
Suitable for distributed water points where physical, nutrient or chemical indicators need continuous observation.
